A part number conversion chart showing the New Miller Diving® Part numbers and the old part numbers that they replace along with the current part name/description is available. The list is sorted by current exploded view location number. Parts that are new will not have a corresponding older Miller Diving® number.

Also available is an Excel format spread sheet of this chart which may be sorted either by the blowapart location number, old miller diving® part number or new part number.

Blowapart location # Old # New # Description
1 4-001 945-001 Helmet Shell, Bronze, painted black
1 4-001 960-384 Helmet Shell, Bronze, polished
2 4-024 910-024 O-Ring
3 4-065 930-065 Manifold Nut
4 4-027 905-027 Muffler, Free flow
5 4-002 920-002 Face Plate
6 4-003 960-003 Face Ring
7 4-017 930-017 Screw
8 4-075 930-075 Nut, Inter Slotted
9 4-012 930-012 Washer
10 4-076 950-076 Nose Device Housing
11 4-077 510-008 O-ring
12 4-078 950-078 Packing Nut, Nose Device
13 4-079 550-065 Nose Knob
14 4-017 930-047 Screw
15 4-100 950-100 Retainer Plate, Side Exhaust
16 4-101 910-101 O-Ring
17 4-102 950-102 Side Exhaust Body
18 4-103 910-103 O-Ring
19 4-029 910-029 Exhaust valve
20 4-104 930-104 Clip Ring
21 4-105 950-105 Exhaust Handle
22 4-133 905-133 Side exhaust assembly
23 4-042 960-304 Regulator Body, M10 (Polished)
23 4-080 945-080 Regulator Body, M10 (Painted Black)
24 4-091 550-060 Piston
25 4-092 535-807 Spring Set
26 4-093 550-059 Spacer
27 4-094 550-058 Adjustment Shaft
28 4-095 520-032 Washer, Teflon
29 4-096 510-011 O-Ring
30 4-097 950-097 Packing Nut, Reg. Adj.
31 4-099 530-601 Roll Pin
32 4-098 950-098 Adjustment Knob
33 4-046 960-046 Regulator Cover (Painted Black)
33 4-046 960-414 Regulator Cover (Polished)
34 4-047 930-047 Screw
35 4-105 950-105 Exhaust Handle
36 4-104 930-104 Clip Ring
37 4-029 910-029 Exhaust valve
38 4-103 910-103 O-Ring
39 4-059 910-059 Deflector
40 4-081 910-081 Diaphragm
41 4-090 530-303 Adjustment Nut
42 4-089 550-052 Spacer
43 4-088 545-038 Roller Lever
44 4-087 530-506 Washer, S.S.
45 4-086 530-505 Washer, Brass
46 4-085 535-804 Spring
47 4-084 545-026 Inlet Valve
48 4-083 510-014 O-ring
49 4-082 950-082 Inlet Seat
50 4-058 910-058 O-Ring
51 4-057 950-057 Retainer Plate, Regulator
52 4-073 910-073 O-Ring
53 4-072 950-072 Mount Tube, Oral Nasal
54 4-017 930-017 Screw
55 4-140

905-140

905-340

Regulator Assembly Painted

Regulator Assembly Polished
56 4-035 915-036 Microphone / Earphone
56 4-036 915-036 Microphone / Earphone
57 4-034 915-034 Speaker Wire Assembly
58 4-033 515-035 Binding Post
59 4-055 905-055 Demand Tube & Guard
60 4-112 930-112 Screw, 10-24 x 5/8"
61 / 930-423 Washer
62 / 905-323 Chin Strap
63 4-017 930-017 Screw
64 4-016 960-016 Neck Ring, Lower
65 4-018 910-018 Neck Seal
66 4-015 960-015 Neck Ring, Upper, Tapped
67 4-135 905-135 Neck Ring Assembly
68 4-009/010 960-006 Cam Handle, EXCHANGE ONLY
69 4-068 930-068 Nut
70 4-012 930-012 Washer
71 4-011 930-011 Screw
72 4-111 955-111 Elbow
73 4-064 945-064 Manifold Valve Body
74 4-063 950-063 Valve Stem, Manifold Valve
75 4-062 920-062 Teflon Packing, Manifold Valve
76 4-060 950-060 Packing Nut, Manifold Valve
77 4-025 930-025 Handle, Manifold Valve
78 4-017 930-017 Screw
79 4-061 930-061 Washer
80 4-134 905-134 Manifold Valve Assembly
81 4-066 510-483 O-ring
82 Order complete #90 One Way Valve Body
83 Order complete #90 Spring
84 Order complete #90 Poppet
85 Order complete #90 O-Ring
86 Order complete #90 O-Ring
87 Order complete #90 Wiper
88 Order complete #90 End Cap
89 / 555-117 Adapter
90 4-019 555-195 One Way Valve
91 / 505-060 One Way Valve Assembly
92 / 950-348 Auxiliary valve body
93 / 550-138 Stem
94 / 540-095 Washer
95 / 520-024 Packing
96 / 550-254 Packing Nut
97 / 520-025 Knob, Control
98 / 535-802 Spring
99 / 550-250 Lock Nut
100 / 905-348 Emergency Valve Assembly
101 4-017 930-017 Screw
102 4-110 950-110 Band Button
103 4-108 905-108 Neck Band
104 4-107 950-107 Adjustment Button
105 / 910-410 Adjustment strap
106 4-106 910-406 Head Harness w/o Adjustment Strap (910-410)
107 4-109 930-109 Washer
108 4-017 930-106 Screw
109 4-005 910-005 Face Seal
110 / 510-575 Nose block pad
111 4-074 545-015 Nose Device
112 4-069 950-369 Valve Body Oral Nasal
113 / 510-552 Valve, Oral Nasal
114 4-070 910-070 Oral Nasal
115 / 915-447 Standoff
116 / 530-308 Nut
117 / 530-525 Washer
118 4-014 920-014 Neck Ring Gasket
119 / 915-445 Insulation Sleeve
120 / 905-175 Locking Strap Assembly
121 / 530-049 Tie Wrap
not shown 4-042 945-042 Regulator Body, Tilt
not shown 4-045 910-045 Diaphragm, Tilt
not shown 4-048 930-048 Screw, Adjustment, Tilt
not shown 4-049 935-049 Spring, Adjustment, Tilt
not shown 4-050 950-050 Knob, adjustment, Tilt
not shown 4-051 950-051 Tilt Valve
not shown

4-052

 935-052 Spring, Tilt Valve
not shown

4-053

 910-053 O-Ring Tilt Valve
not shown 4-054 950-054 Housing Tilt Valve
not shown 4-067 955-067 Plug
not shown 4-113 960-113 Face Guard
not shown 4-114 960-114 Weld Shield, Flip-up
not shown 4-115 940-115 Hinge, Welding Shield
not Shown 4-116 930-116 Screw, Nylock
not Shown 4-117 930-117 Rubber Washer
not shown 4-137 905-137 Face Guard Assembly
not shown 4-138 905-138 Welding Shield Assembly
not shown 4-144 925-144 O-ring kit
Order as individual parts 4-069

950-369

910-335 Valve
Order as individual parts 4-130

915-036 Microphone, Earphone

915-034 Wire Assembly
Order as individual parts 4-136

910-406 Head Harness

910-410 Adjustment Strap
Order as individual parts 4-131

950-369

910-335 Valve

910-070 Oral Nasal

910-073 O-ring

950-072 Mount Tube
Order as individual parts 4-132

930-075 Nut, Slotted

930-012 O-ring

950-076 Housing

510-008 O-ring

950-078 Packing Nut

550-065 Knob

545-015 Nose Device

510-575 Nose Device Pad


4-400

900-400

 400 Miller Diving® Helmet complete
